Mechanical Fluid Flowmeter
FM-120 Mechanical fluid Flowmeter can measure refueling quantity with reliable quality, low price, and easy installation and calibration.
Description
Mechanical fluid Flowmeter
FM-120 Mechanical fluid Flowmeter can measure refueling quantity with reliable quality, low price, and easy installation and calibration.
FM-120 Mechanical fluid Flowmeter has an aluminum casing and a 1'' threaded connection. The meter can display three single refueling volumes that can be manually reset to zero, and a six-digit total that cannot be reset to zero.
|
Model |
FM-120-1 |
FM-120-2 |
FM-120-3 |
FM-120-4 |
|
measurement |
liters/gallon |
liters/gallon |
liters/gallon |
liters/gallon |
|
Max pressure |
3 Bar |
3 Bar |
3 Bar |
3 Bar |
|
Flow |
150LPM |
120LPM |
120LPM |
100LPM |
|
In/outlet |
BSPF/NPT1”or1.5” |
BSPF1” |
BSPF1” |
BSPF1” |
|
Precision |
+-1% |
+-1% |
+-1% |
+-1% |
|
Package |
6pcs/carton |
6pcs/carton |
6pcs/carton |
6pcs/carton |
|
N.W |
15KG |
12KG |
12KG |
9KG |
|
G.W |
16KG |
13KG |
13KG |
10KG |
|
Package Dimension |
520*260*350mm |
520*260*350mm |
520*260*350mm |
520*260*350mm |
Application FM-120 mechanical flowmeter
FM-120 is a mechanical flow meter used for measuring the volume of various liquids including gasoline, diesel, kerosene, and other fuels. It is commonly used in fuel dispensing systems for accurately measuring the amount of fuel dispensed to the customer. It is easy to install, calibrate, and maintain, and it provides accurate readings of fuel flow rate. The FM-120 mechanical flow meter is compatible with a wide range of fuel transfer pumps and is designed for use in both stationary and mobile fueling applications.
Advantages of FM-120 mechanical flowmeter
Accuracy: The FM-120 flowmeter is highly accurate and can measure flow rates with an error margin of less than 1%.
Durability: The meter is made of high-quality materials such as aluminum, which is durable and resistant to corrosion. This ensures that the flowmeter can last for a long time even when used in harsh conditions.
Easy to read: The meter has a large, easy-to-read display that shows the flow rate in liters or gallons. This makes it easy for the user to monitor the flow rate at a glance.
Easy to install: The flowmeter is easy to install and can be attached to the fuel dispensing system using standard fittings. This makes it easy to retrofit the meter to existing systems.
Cost-effective: The FM-120 flowmeter is relatively inexpensive compared to other flowmeters, making it an affordable option for small businesses and individuals who need to measure fuel usage.
