Truck Gangway (also referred to as Loading Gangway, Access Ladder, 3-step / 4-step / 5-step Gangway)

Truck gangway is essential safety equipment for petrochemical loading racks. It is specially designed for operators to safely board tank truck tops from the platform, connect loading arms, take samples and perform inspections.

Core Functions

Safe access: Connects loading rack and tank truck top, with fall protection, anti-slip and anti-static performance

Flexible adaptability: Accommodates various heights and vehicle types (truck / rail tankers)

Self-balancing: Holds position at any angle, steps remain horizontal at all times

Mandatory compliance: Required for top-loading operations of hazardous chemicals (GB 50160)

Main Structure

Main frame: Galvanized carbon steel / 304 stainless steel

Parallel four-bar linkage: Keeps steps horizontal

Spring cylinder balancing system: Light lifting effort, locks at any position

Anti-slip steps: Serrated grating, anti-slip coefficient ≥ 0.5

Safety railings: Hand & knee rails, safety chains / latches

Anti-collision bumpers: Prevent impact and static sparks at tanker contact

Foot-actuated lock: Step down to lock, lift to release

Common Specifications

3-step Gangway

Span: 1.2～1.5 m

Application: Low platforms, road tankers

4-step Gangway

Span: 1.6～1.8 m

Application: Medium-high platforms, general purpose

5-step Gangway

Span: 2.0～2.5 m

Application: High platforms, rail tankers

Key Parameters

Load capacity: 200 kg

Material: Galvanized carbon steel / 304 stainless steel

Angle range: 90° upward, 45° downward

Installation: 4×M16 bolt-on / welded

Safety: Anti-static grounding, anti-slip, fall protection
